Directional Wired Ceiling Mount Pir Motion Sensor White

Note: Do Not Mount The Unit In Direct Sunlight Or Near Heat Sources.
Overview:
This Product Is A Ceiling-Mount Curtain Passive Infrared Detector Exquisite Design Easy Installation. Fit For The Locations Of The Family Balcony/ Office Entrance Door Etc. Imported High-End Infrared Sensor Smt Chip Technology Anti-Emi Anti-Rfi Design Temperature Compensation Pulse Count Optional Led Switch Selectable Functions It Could Work With Wired Alarm Host.Features:
*Intelligent Logic To Prevent False Alarms. Smt Chip Technology Anti-Emi Anti-Rfi Design. Automatic Temperature Compensation Pulse Count.
*The Directional Ceiling-Mount Pir Detector With 2 15 Curtain Detecting Angle Can Automatically Identify Which Direction The Person Is Coming From More Accurate Than Normal One.
*2 Independent Dual Source Infrared Sensors Detection Range Of 2 Sensors Are 67Cm 4.8M And 60Cm 4.8M.
*2 Relays Output Which Can Distinguish Between Enter In And Go Out. Can Set The Return Time.
*Widely Used For Family Balcony Access Personnel Statistics And Anti-Theft For Bank Atm Machine And 24-Hour Place Of Business Etc.Specifications:
Input Voltage: 12V-16V
Current Consumption: 15Ma
Curtain Detector Angle: 2*15
Detecting Range: 67Cm 4.8M And 60Cm 4.8M
Rfi/Emi Rejection: 10V/M From 10Mhz To 1Ghz
Alarm Output: 100Ma/28Vdc N.C.
Tampter Output: 150Ma/28Vdc N.C.
Detection Speed: 0.2M/S - 3.5M/S (0.65Ft/S - 11.4Ft/S)
Led Indication: On/Off Optional
Installation Way: Ceiling Mounting
Installation Height: 2.1M-3.6M (7Ft To 12Ft)
Casing Material: Abs
Item Size: Approx. 10.8 * 10.8 * 3.5Cm
Item Weight: Approx. 70G / 2.5OzPackage Information:
Package Size: Approach. 10.8*10.8*3.8Cm/ 4.3*4.3*1.5In
Package Weight: Approach. 94G / 3.3OzStrong>Package List:
1 * Wired Curtain Pir Motion Sensor
1 * User Manual (English)
